380 V Coil K type Gutter Cold Roll Forming Machine 0.3mm - 0.8mm

380 V Coil K type Gutter Cold Roll Forming Machine 0.3mm - 0.8mm

K type Gutter roll forming machine line

Technique parameter

• Coil material: color steel, aluminum, copper
• Forming station: Abt 17
• Forming speed : 12m/min,stop to cut
• Power: 5KW, 380 V, 3 Phase 50Hz
• Material of Axis: High grade 45# steel
• Diameter of Axis: φ80mm
• Material of Roller: High grade 45#, polished and coated with 0.05mm Chrome Surface.
• Materical of Machine Frame: A3 Steel, thickness 18mm
• Electrical Control: PLC Frequency Control System with touch screen
• PLC/Screen/Frenquency convertor: PANASONIC Brand
• Encoder: OMRON Brand
• Cutting type: up: one blade down: two blades
• Dimension of machine: Abt. 8m*0.9m*1.3m
• Machine wight: abt. 8 Ton

Main component

Working flow:

Passive decoiler---- feeding & guiding---- roll forming--- straightening-- hydraulic cutting---run out table

Application

downspout, rainspout,Rainwater downpipe, drainpipe, water pipe
